Radical-7 Chapter 3: Setup
www.masimo.com 61 Masimo
• The Battery Charging indicators on the Docking Station flash
prior to charging and remain illuminated while the batteries
are charging.
See
Standalone Front Panel on page 54 and Battery Operation and
Maintenance on page 196.
Setting Up for Philips, Agilent, or HP VueLink
To set up for use with VueLink compatible monitors (Philips, Agilent, or HP)
1. On the Radical-7, on the
device output screen, for the serial
option, select Hp VueLink.
2. Connect one end of the VueLink cable to the Serial Output
connector on the Docking Station.
3. Connect the other end of the VueLink cable to the VueLink
module and insert the module into the VueLink compatible
monitor rack.
The SpO
2
and pulse rate values appear on the VueLink
compatible monitor.
4. In order for the plethysmographic waveform to be displayed on
the VueLink compatible monitor, and for the VueLink monitor to
convey alarm conditions measured by the Radical-7, the VueLink
compatible monitor must be properly configured.
5. See instructions for use provided with the VueLink compatible
monitor and the VueLink module. See
Compliance on page 183
and
Serial Interface Specifications on page 186.
