Radical-7 Chapter 8: Specifications
www.masimo.com 188 Masimo
Serial RS-232 (RDS-1, RDS-3)
Nurse Call/Analog Output (RDS-1, RDS-3)
VueLink, (Philips, Agilent, HP, Spacelabs Flexport, RadNet, SafetyNet
(RDS-1, RDS-3)
Serial Interface Specifications
The digital interface for serial communication is based on the standard
RS-232 protocol. The Radical-7 by default always outputs ASCII 1 text
data through the serial port, unless the user selects a different output
mode. To interface with the Radical-7 and receive serial text data, connect
a serial interface cable with a ferrite bead installed to the serial output
connector located on the back of the Radical-7 Docking Station. The
Radical-7 serial interface is only available when the Radical-7 Handheld is
properly attached to the Docking Station. Once serial communication is
established, packets of data are communicated at 1 second intervals. See
Device Settings on page 116.
Serial Interface Setup
To interface with the Radical-7 serial port, set the following
communication parameters on the interfacing serial device:
Parameter Setting
Baud rate 9600 baud bi-directional
Number of bits per character 8
