Radical-7 Chapter 4: Operation
www.masimo.com 129 Masimo
1. From the Display View , in the Trend Field , touch the icon as
shown below.
2. From the
Full Trend screen , touch the icon as shown below.
Using the Events Feature
The Events feature provides graphical display of parameter or
measurement alarms and non-clinical exception messages. This feature is
only viewable in the Full Trend screen; however, it is available at all times
for all parameters and measurements. For more information about these
alarms and exceptions, see Chapter 6: Alarms and Messages.
Events appear as color-coded circles along the trend of a parameter or
measurement.
