Radical-7 Chapter 4: Operation
www.masimo.com 143 Masimo
Color Description Table
This visualization displays a human body on the Radical-7 device when it
is connected to Root. Colors are used to represent the status of
monitoring and the alarms:
Color Description
Gray No monitoring
Green Monitoring, normal range
Yellow
Monitoring, caution range
Red Monitoring, alarm range
Parameter Visualization Table
Alarms for various parameters and/or measurements are displayed as
follows:
Area Displayed on Visualization Screen
SpO
2
Lung
PR Heart
PI N/A
