10
5.0 Operational Sequence (For various steps refer images shown in the bracket)
5.1 Before First Light-up
- Make sure that the burner is correctly installed and signed off by an approved installer.
- All local council’s wood fire permission or permit requirements have been completed satisfactorily.
- Make sure that all the packing material has been removed from both the combustion chambers.
Please note that the special high temperature paint is used in the firebox that will emit some smoke as it cures
during initial two to three sessions of running. Ventilate the house during these initial burns. While curing the
surface heated paint softens, so do not touch hot surface during this process. Babies, small children, pregnant
women, elderly persons, persons subject to pulmonary hypersensitivity and pets should avoid exposure to this
smoke. Open doors and windows and use a fan, if necessary. After these initial burns, there should be no smoke.
5.2 Cold Start- up
- (5.2A) Make sure the bottom combustion chamber door is closed and ceramic block is sitting in place at the
rear of the chamber
- (5.2B) The burner is connected mains power and Fan switch is in the “ON” position
- (5.2C) The LED on the front bottom panel should be “RED”
- (5.2D) Set the damper handle to “OPEN” position
5.2A 5.2B 5.2C 5.2D
5.3 Stack & Light Kindling
- (5.3A) Open the top combustion chamber & Load 4 pieces of kindling around & top of the downdraft injector.
- (5.3B) Place 2 firelighters as shown
- (5.3C) Load the remaining kindling over the firelighters in stack formation
- (5.3D) Light the fire starters and close the door
5.3A 5.3B 5.3C 5.3D
5.4 Intermediate Load 1 & Green LED
- (5.4A & 5.4B) In about 4-5 mins, kindling will be fully alight. Open the door, add 4 pieces of intermediate 1
load – approx. 1.2 kg and then close the door.
- Now onwards, always ensure that all fuel logs are loaded with “Front to Back” orientation with slightly at an
angle in the firebox.
- (5.4C) in about 10-12 mins, the “GREEN” LED will light when an optimum conditions are reached for the
downdraft operation mode.
- (5.4D) Turn damper handle from “Open” to “Close”. This sets the burner into downdraft mode.
To Next Page
