3
1.0 Introduction
Congratulations! You are the owner of a state-of-the-art Ultra Low Emission Burner “Masport
Mystique” designed and developed by Glen Dimplex New Zealand. Thank you for purchasing a Masport
appliance.
MYSTIQUE burner is a new generation wood fire, designed to provide you with all the warmth and charm of
a fireplace, at the same time have negligible emissions with dramatically reduced impact on the environment.
This model has been approved by Environment Canterbury for installation in all of their clean air zones that
have been banned for installation of a conventional wood burner. As it bears the Masport brand, it promises
to provide you with economy, safety and efficiency.
To make the most of your appliance, it is important to install, operate and maintain the burner correctly.
Please read this installation and operations manual carefully before installing or operating your MYSTIQUE
fire. Please take time to understand the basic principles of this new burner which uses down draft
combustion technique. .
Conventional Masport burner has a single firebox and uses triple combustion technique with preheated
combustion air. Injection of preheated air jets in different direction bombards the fire bed and creates a very
hot turbulent flame to burn most of the polluting particles at around 600~700
o
C. Though this is a clean way
of burning, some particulate and valuable heat energy escapes to atmosphere through an exhaust flue pipe.
Mystique burner has a firebox with two combustion chambers and a heat exchanger at the rear of these two
chambers. Fuel is loaded and ignited in the top combustion chamber where primary combustion takes place.
After initial primary burning, when the overall burner is hot enough and sustained flue draft is created, flue
gases are directed downward into bottom combustion chamber by closing the damper in upper section of the
firebox. The exhaust gases passing through the red hot embers get re-ignited and burns at temperature
higher than 1000
o
C. The extreme hot temperatures and turbulence created while passing through ember
bed, burns almost all the particulate matter. Further, these hot gases passes through a heat exchanger to
extract maximum heat from the exhaust gases and reduces its temperature down to 250
o
C. Overall, the
result of this downdraft combustion technique is very efficient burning with maximum heat with less fuel
consumption and negligible emissions.
1.1 Items supplied with the fire
- Mystique Burner
- 600mm Mystique St/St Double Skin Flue Shield
- Accessory Pack – which contains
- 1 x 4mm Allen Key for bottom combustion chamber
- 1 x Installation and Operations Manual
- 1 x Seismic bracket
- 1 x ceramic block
1.2 Handling and Transport
The MYSTIQUE fire is heavy and tall in size with total weight of 175 kgs.
Single person handling could cause injury, hence Masport recommends suitable handling equipment or two
persons while handling, both outside and inside the house.
All precautions have been taken during designing of packaging so that the fire reaches customer’s house
without any damage. In case any damage is found while opening the fire, please report it to your dealer and
to Masport immediately before installing the fire.
