7.0 Mystique Replacement Parts
Some parts of Mystique burner are considered consumable. These parts will wear out or degrade over time.
The life of these parts will vary upon
- How frequently the fire is used
- Type of fuel. Some species of wood fuel are harsher than others.
Following items are considered as consumables.
Boards & Bricks
- Set for Top Combustion Chamber
- Set for Bottom Combustion Chamber
- Ceramic Block
Seals
- Top Door Seal
- Bottom Door Seal
- Damper Seal
Glass
- Top Combustion Door Glass
- Bottom Combustion Door Glass
Downdraft Injector
- Top Downdraft Injector
- Injector Coupler
These consumable parts should be replaced as soon as they show signs of wear. Running your burner with
worn or broken parts may result in reduced output, increase in fuel consumption and even can damage the
firebox or other vital parts of the burner. We highly recommend frequent visual check of these consumables
and other parts of the burner.
Other Spare Parts
Electrical & Electronics
Convection Fan
Electronic Controller
Electrical Looms
Thermocouple 1
Thermocouple 2
Other
Top Door Handle Kit
Bottom Door Handle Kit
Damper
Refer Fig 7.1 & Fig 7.2 for schematic of Mystique parts and Insulation Board layout.
