4-23
Front and Rear Shock Adjustment
The spring preload can be adjusted to suit
the operating conditions.
You can reduce preload for a softer ride, or
increase preload if frequent bottoming
occurs.
1
CAUTION:
Frequent or severe bottoming can cause
increased wear or damage to the vehicle.
Adjust the spring preload as follows.
To increase the spring preload, turn the
adjusting ring in direction .
To decrease the spring preload, turn the
adjusting ring in direction .
1. Spring preload adjusting ring
2. Position indicator
NOTE:
A special wrench can be obtained at a dealer
to make this adjustment.
Standard position: B
A-Minimum(soft)
E-Maximum(hard)
