Indicator and Warning Lights
1. High-range indicator light “H”
2. Parking brake indicator light “P”
3. Low-range indicator light “L”
4. On-Command differential lock indicator “DIFF. LOCK”
5. Neutral indicator light “N”
6. Reverse indicator light “R”
7. On-Command four-wheel-drive indicator “ ”/ “ ”
8. Emergency indicator
9. Position light indicator
10. High beam indicator
11. Coolant temperature warning light “
”
Low-Range Indicator Light “L”
This indicator light comes on when the drive
select lever is in the “L” position.
Parking Brake Indicator Light “P”
This indicator light comes on when the
parking brake is applied.
High-Range Indicator Light “H”
This indicator light comes on when the drive
select lever is in the “H” position.
On-Command Differential Gear Lock
Indicator Light “DIFF. LOCK”
This indicator light in the display come on
when the “UNLOCK” switch in the
“On-Command Four-Wheel–Drive and
Differential Gear Lock Switches” is not set to
