Multi-Function Display Gauge
1. Left turn indicator
2. Speedometer
3. Tachometer
4. Right turn indicator
5. Metric/mile button
6. “TRIP/ODO” button
7. Clock/Hour/
fault code meter
8. Odometer/Trip meter A / Trip meter B
9. Clock/Hour/
fault code reset button
The multi-function meter unit is equipped
with the following:
Speedometer (which shows the riding
speed)
Odometer (which shows the total distance
traveled)
Two trip meters (which show the distance
traveled since they were last set to zero)
Clock
Hour meter (which shows the total time
the key has been turned to “ON”)
Fault code meter （To display the faults of
Electronic Fuel Injection system）
