Sundry Box Cover
To Open/ Close
Unhook the hood latches, and then slowly tilt
the sundry box cover up. To close, tilt cover
back to closed position and fasten the
latches.
1. Sundry box cover
Engine Cover
To Open/ Close
1. Remove two seats ( see page 4-16 )
2. Unscrew all the screws on the engine
cover.
3. Pull the engine cover upward to open it.
1. Engine cover 2. Screw (M6×12)
1CAUTION:
When installing the engine cover, be sure
not to pinch the cables or wires.
