8-14
6. Install the oil filler bolt, and then tighten it
to the specified torque.
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 16.3 ft·lbs)
7. Check for oil leakage. If oil leakage is
found, check for the cause.
Differential Gear Oil
Checking the Differential Gear Oil Level
1. Place the vehicle on a level surface.
2. Remove the differential gear oil filler bolt
and check the oil level. It should be up to
the brim of the filler hole. If the level is
low, add sufficient oil of the
recommended type to raise it to the
specified level.
1. Speed sensor 2. Correct oil level
3. Differential gear oil 4. oil level sensor
1CAUTION:
1.Be sure no foreign material enters the
differential gear case.
2.Please clean the sensor every 500km
(310miles).
