8-13
Changing the Final Gear Oil
1. Place the vehicle on a level surface.
2. Place a container under the final gear
case to collect the used oil.
3. Remove the oil filler bolt and the drain
bolt to drain the oil.
1. Final gear oil drain bolt
4. Install the drain bolt, and then tighten it to
the specified torque.
Tightening torque:
Final gear oil drain bolt:
20 Nm (2.0 m·kgf, 14 ft·lbs )
5. Add the recommended final gear oil up to
the brim of the filler hole.
Recommended oil:
SAE 80 API GL-4Hypoid gear oil
Oil quantity:
0.4 L (0.35 lmp qt, 0.42 US qt)
1CAUTION:
Be sure no foreign material enters the final
gear case.
