Massimo MSU 800 - Drive Select Lever Operation and

6-4
Drive Select Lever Operation And
Driving In Reverse
Before shifting, you must stop the UTV and
return the throttle lever to the closed position,
otherwise the transmission may be
damaged.
Shifting: Neutral to High and High to Low
1. Bring the UTV to a complete stop and
return the throttle lever to the closed position.
2. Apply the brakes, then shift by moving the
drive select lever along the shift guide.
NOTE:
Make sure that the drive select lever is
completely shifted into position.
1. Drive select lever
Shifting: Neutral to Reverse
NOTE:
The drive select lever cannot be shifted into
or from reverse without applying the brake.
