Chapter 5. How to control RS-232C communication
5.1 Prepare RS-232C communication
1) Prepare to 9p to 9s.(Use the cable provided from Master Co., Ltd)
2) Connect MSPG-8000’s RS-232C port to PC via 9p to 9s cable.
3) MSPG-8000 communication setting value
① Baud rate: 9600 or 19200 (Check the manual page at 80)
② Data Bits: 8
③ Stop Bits: 1
④ Parity: None
⑤ Device: User computer’s comport number
4) RS-232C flow chart
MSPG-8000
MSPG-8000
