Master MSPG-8000 - Specification of MSPG-8000

Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 13
2.3 Specification of MSPG-8000
MG-HDMI2.0/ARC
HDMI 2.0 x 2port
Compliant
HDMI 2.0 Version
Pixel Rate Range
25MHz~600MHZ/4Kx2K/60Hz(600MHz)
Video Signal Type
RGB, YCbCr
Pixel Encoding & Data
bit of RGB & YCbCr
4K@30Hz_RGB444(8, 10, 12 bit), YCbCr444(8, 10, 12 bit), YCbCr422(8, 10, 12 bit)
Data bit of RGB
&YCbCr
4K@60Hz_RGB444(8bit only), YCbCr444(8bit only), YCbCr422(8bit ,10,12bit)
Color Space
RGB, BT-601, BT-709, BT-2020, xvYCC-601, xvYCC-709
HDCP
Support HDCP 1.4 and 2.2 Version
Output Connector
Type A, HDMI 2 Port (4K x 2K @60Hz 2Port, ARC 2Port)
Note
Audio Return Channel (ARC) 2Port, CEC Support
3D Video Formats (Frame Packing, Side by Side, Top & Bottom, Field Alternative)
D/L port
Firmware & Data up-load port
Digital Audio
2Ch Audio
Optic ARC x 2port
Digital Audio
SPDIF (Audio Return Channel)
MG-DISPLAYPORT1.3
Displayport 1.3 x 2port
Compliant
Displayport 1.3 Version
Pixel Rate Range
8K x 4K@30Hz(7680x4320@30Hz), HBR3
Video Signal Type
RGB, YCbCr
Color Space
RGB, BT-601, BT-709
HDCP
Support HDCP 1.3 and 2.2 Version
Output Format
RGB444, YCbCr444(8, 10, 12 bit)
YCbCr422(8, 10, 12 bit)
Digital Audio
I2S, 48KHz, 2 Channels
MG-ANALOG/DVI
Analog x 1port
Pixel Rate Range
8~250MHz
Video Signal Type
R, G, B (Load 75 ohms, 0~1.0V Programmable)
Output Connector
15P D-Sub
Separate Sync
HS, VS(3.0V~5.5Vp-p Programmable)
Analog Audio x 1port
Analog audio
Stereo L, R
DVI Dual x 1port
Compliant
DVI 1.0 Support
Pixel Rate Range
* Dual Link: 25~330MHz
Transfer Type
* Single TMDS 24 Bit Input Mode
* Dual TMDS 12 Bit Input Mode
HDCP
Support HDCP 1.3
