Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 14
Video Signal Type
RGB
Output Connector
DVI-D (DVI 1Ports, Single/Dual)
DVI Audio x 1port
Analog audio
Stereo L, R
MG-S-VIDEO/CVBS
S-VIDEO/CVBS x 1Port
Output Mode
* NTSC M,J (3.58MHz)
* NTSC443 (4.4MHz)
* PAL B, D, G, H, I (4.434MHz)
* SECAM (For=4.406MHz / For=4.25MHz)
Subcarrier Stability
25ppm (±25Hz / 1MHz)
Video Output
Composite (BNC), S-Video
* Signal: CVBS (Connector: BNC)
* Signal: Y/C (Connector: 4Pin-Mini Din)
S-VIDEO/CVBS
Audio L/R
Analog audio
RCA L, R
MG-S-VIDEO/CVBS/SCART
Same as MG-S-VIDEO / CVBS slot
SCART X 1Port
(Monitoring x 1port)
Output Mode
PAL only
Output Connector
SCART 21pin
MG-COMPONENT
COMPONENT(YPbPr) x
1port
output mode
Y, Pb, Pr(480i/p, 576i/p, 720p, 1080i/p for ATSC and DVB Format)
Output Connector
BNC
COMPONENT Audio
L/R
Analog audio
RCA L, R
MG-HDMI2.1/ARC-1
HDMI 2.1 X 1Port
Compliant
HDMI2.1 Version
Pixel Rate Range
25MHz~1.2GHz / 8Kx4K@60Hz
Signal Type
TMDS, Fixed Rate Link (FRL – Maximum link : 10Gbps x4Lane
Pixel Encoding & Date
Bit of RGB & YCbCr
8K@30Hz_RGB444(8/10bit), YCbCr444(8/10bit), YCbCr422(8/10/12bit)
8K@60Hz_YCbCR420(8/10bit)
Color Space
RGB, BT-601, BT-709, BT-2020, xvYCC-601, xvYCC-709
HDCP
Support HDCP 1.4 and 2.3 Version
Output Connector
Type A, HDMI 1 Port (8K x 4K @60Hz 1Port)
Note
3D Video Formats (Frame Packing, Side by Side, Top & Bottom, Field Alternative)
D/L port
Firmware & Data up-load port
Digital Audio
8ch audio
Optic ARC X 1Port
Digital Audio
SPDIF ( Audio Return Channel)
MG-USB TYPE-C
