Master MSPG-8000 - Panel and Their Functions

Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 17
2.4 Panel parts and their functions
1) Front panel of MSPG-8000
① Power On/Off ②Touch LCD Screen ③Slot select ④Function buttons ⑤Numb. buttons ⑥Direction button
① Power On/Off switch
② Touch Screen LCD
③ Slot select buttons 1~8
④ Function buttons
⑤ Number buttons
⑥ Cursor and ok(enter) buttons
