5.2 HEX code and ASCII code
COMMAND
HEX CODE
ASCII CODE
On-Line
0x05
No need
Off-Line
0x04
No need
Start
0x02
No need
End
0x03
No need
Slot select
0x1F
run slot 1~8;
Time select
0x07
run time 1~999;
Pattern select
0x08
run pattern 1~999;
Time & Pattern select
0x09
In the future
Audio select
0x13
run audio 1~39;
HDCP ON/OFF select
0x12
run hdcp on; OR run hdcp off;
HDCP 1.4/2.2 on/off
0x15
run hdcp ver 1.4; OR run hdcp ver 2.2;
HDR select
0x16
In the future
5.3 Hex code RS-232C control example
1) On line: 0x05 (★Be sure to send an on-line command(0x05) first to order communications)
Off line: 0x04 (Send it to end the communications)
Command
On line
05
Of line
04
2) Slot select: 0x1F + Slot No. 0x31~0x38
Command
Start
02
Slot select
1F
Slot No.
31~38
End
03
Slot No.1
02
1F
31
03
Slot No.7
37
3) Time change: 0x07 + Time No. 0x30~0x39 3code
Command
Start
02
Time select
07
Time No.
3x 3x 3x
End
03
Time No.98
02
07
30
39
38
03
Time No.152
31
35
32
4) Pattern change: 0x08 + Pattern No. 0x30~0x39 3code
Command
Start
02
Pattern select
08
Pattern No.
3x 3x 3x
End
03
Pattern No.52
02
08
30
35
32
03
Pattern No.1
30
30
31
