5) Time & Pattern change: 0x09 + Time No. 0x30~0x39 3code + Pattern No. 0x30~0x39 3code
Command
Start
02
T&P select
09
Time No.
3x 3x 3x
Pattern No.
3x 3x 3x
End
03
T.371&P.52
02
09
33
37
31
30
35
32
03
T.463&P.1
34
36
33
30
30
31
6) Audio On/Off: 0x13 + audio on/off command 0x32 + audio off 0x30/audio on 0x31
Audio number select: 0x13 + Audio Type 0x30~0x31 / 0x31~0x39
Command
Start
02
Audio
13
Off/On
32
Audio off 30
Audio on 31
End
03
Audio Off
02
13
32
30
03
Audio On
31
Command
Start
02
Audio
13
Type
31
Audio Number
3x 3x
End
03
Audio No.2
02
13
31
30
32
03
Audio No.25
32
35
7) HDCP On/Off setting: 0x12 + HDCP OFF 0x30/HDCP ON 0X31
Command
Start
02
HDCP ON/OFF
12
HDCP ON/OFF
30/31
End
03
HDCP OFF
02
12
30
03
HDCP ON
31
8) HDCP On/Off & Version setting: 0x15 + 0x30(off) / 0x31(on) + 0x30(HDCP1.4)/0x31(HDCP2.2)
Command
Start
02
HDCP select
15
HDCP ON/OFF
30(OFF)/31(ON)
HDCP 1.4/2.2
30(1.4)/31(2.2)
End
03
HDCP 1.4 off
02
15
30
30
03
HDCP 1.4 on
31
30
HDCP 2.2 off
30
31
HDCP 2.2 on
31
31
9) HDR setting: 0x16 + 0x04(EOTF) + 0x32/33
Command
Start
02
HDR
16
EOTF
04
EOTF select
32~33
End
03
Reserved
02
16
04
Reserved
03
Reserved
Reserved
HDR10
32
HLG
33
