Master MSPG-8000 - Page 15

Slot Type Multi Video Signal Generator MSPG-8000
www.Ltdmaster.com 15
USB TYPE-C X 1Port
Compliant
Displayport 1.2Ver
Pixel Rate Range
Max 4K x 2K@60Hz Resolution
Pixel Encoding & Date
bit of RGB & YCbCr
HBR2(4Lanes)
RGB444(8/10bit), YCbCr444(8/10bit), YCbCr422(8/10bit),
4K x 2K@60Hz RGB 444 8bit only
HDCP
HDCP 1.4 and 2.2
Color Space
RGB, BT-601, BT-709
Output Connector
USB TYEP-A (Device)
USB TYEP-B (Host)
USB TYEP-C (Dual role port)
POWER : External power source connector to MSPS-100W
LOAD : External electric load connector to MSDL-100W
USB Pass-thru
USB3.1(5Gbps) and USB 2.0 pass--thru
Power Delivery(Source)
Up to 20V/5A(100W) with external power test unit MSPS-100W (Optional)
Power Delivery(Sink)
Up to 20V/5A(100W) with external load test unit MSDS-100W (Optional)
D/L Port
Firmware & Data up-load port
Digital Audio
I2S, 48KHz, 2Channels
COMMON Spec.
Digital Audio
Common Spec.
Sample Rate
32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192KHz
Number of Channel
8 Channels
Bit per Sample
24
Waveform
Sine Wave
Frequency Range
20Hz to 24KHz / 5Hz step
Level Range
0dB to -110dB/ 0.5dB step
External Audio Input
Optical, Coaxial
Special Control Mode
Fix, Sweep, Swap, Optical, Mute
Analog Audio
Common Spec.
Frequency Range
20Hz to 24KHz / 5Hz step
Level Range
0mVrms to 900mVrms / 5mVrms, 0~18dB
Waveform
Sine Wave
Number of Channel
2 Channels
Connector
RCA
Special Control Mode
Fix, Sweep, Swap, Mute
Scan Storage
Scan Storage
99 Group (1 Group; 40 Step)
Function Storage
Function Storage
99 Group (1 Group; 30 Step)
Data Storage
Timing
999 Timing (User: 1~500, Default: 501~999)
Pattern
999 Pattern (User: 1~500, Default: 501~999)
MSPG-8000 main body
Reset
MSPG-8000 main firmware download reset button
