Masterclock GMR5000 User Manual



MasterclockGMRUserManualv2–2016.12
43
 CustomSettings:
DaylightSavingTime:Disabledaylighttime=ON
TimeZone/TimeOffset:Bias=00:00:00

TimeCodeGenerator:
 TypeofTimecodetoGenerate=SMPTE30framespersecond
 SMPTEextraencoding=SMPTELeitchdateencoding
 TimeToGenerate=UTC
 ScheduledTimeofDropFrame
Jam=00:00

NMEA:
Messages=NONE
OutputPort=RS232(DB‐9)
PortSettings:
Baud=9600
DataBits=8
StopBits=1
Parity=None

NENA:
EnableNenaFormat0Output=OFF
EnableNenaFormat1Output=OFF
EnableNenaFormat
8Output=OFF
DisabledLockIndicatorinNenaOutput=OFF
OutputPort=RS232(DB‐9)
PortSettings:
Baud=9600
DataBits=8
StopBits=1
Parity=None

Truetime/Kinemetrics:
 Enable=OFF
 DisabledLockIndicatorinTruetime/KinemetricsOutput=OFF
 Time
Output=Local
PortSettings:
Baud=9600
DataBits=8
StopBits=1
Parity=None

ProgrammablePulseOutput:
OutputMode=Stopped
InitialOutputState=High
Interval1=.0005seconds
Interval2=.0005seconds

Allowtimeserver(NTP/IRIG/SMPTE)duringreferenceoutages
=ON
Durationtimeserverisallowed=86400seconds

SyncInput:
SyncNENAinputtopulseinput=OFF
SyncNMEAinputtopulseinput=OFF
SyncNTPinputtopulseinput=OFF
Syncmanually‐settimetopulseinput=OFF
SYNC_INPulseInputRequired=
ON
