Masterclock GMR5000 - PTP Profile Settings; Resetting PTP to Defaults; Setting Default PTP Profile (E2 E); Setting Default PTP Profile (P2 P)



MasterclockGMRUserManualv2–2016.12
62
improvetheaccuracycomparedtheE2E,butallofthenetworkinfrastructuremustsupportthe
P2Pdelaymechanism.
logMinPdelayReqInterval–UsedwhentheP2Pdelaymechanismisselected.Thevalueis
logarithmtothebase2.Anegativevalueisafractionalsecond.Recommendedvalueis1,range0
to4.

6)Disableanyactiveprofile
Disablesanyactiveprofile.DoesnotchangeanyofthePTPsettings.
7)SetPTPtodefaults
SetsallofthePTPsettingstotheirdefaults.
8)SetPTPtodefaultprofileDelayRequest‐Response(E2E)
SetsPTPtothedefaultDelayRequest‐Response(E2E)profileasdefineinAnnexJoftheIEEEStd1588‐
2008.
9)SetPTPtodefaultprofilePeer‐to‐Peer(P2P)
SetsPTPtothedefaultPeer‐to‐Peer(P2P)profileasdefineinAnnexJoftheIEEEStd1588‐2008.


