MasterCraft 055-6751-6

36 37
model no. 055-6751-6 | contact us 1-800-689-9928
PARTS LIST
     
51 Screw 2 76 Spring 1
52 Bearing 1 77 Sliding lock knob 1
53 Gear box cover 1 78 Bearing cover 2
54 Flat key 1 79 Screw 4
55 Spindle 1 80 Hex bolt 1
56 Inner ange 1 81 Bevel lock knob 1
57 Inner teeth washer 2 82 Washer 1
58 Moving guard wheel 2 83 Bever angle scale 1
59 Clamp screw knob 1 84 Straight bearing 3
60 Moving guard 1 85 Buffer ring 2
61 Locknut 2 86 Shoulder screw 2
62 Washer 6 87 Connection rod 1
63 Laser warning label 2 88 Wave washer 3
64 Moving guard torsional spring 1 89 Shoulder screw 1
65 Screw 1 90 Support 1
66 Shoulder screw 1 91 Spring washer 4
67 Guard support 1 92 Hex socket screw 4
68 Hex bolt 1 93 Laser 1
69 Hex reverse screw 1 94 Screw 1
70 Outer ange 1 95 Laser holder 1
71 Blade 1 96 Cutting depth location plate 1
72 Hex key store 1 97 Washer 1
73 Hexagon screw 1 98 Location pin 1
74 Hex key 1 99 O-ring 1
75 Crank arm 1 100 Lock-down pin knob 1
PARTS LIST
     
101 Rotary shaft 1 121 Spring washer 3
102 Torsional spring sleeve 1 122 Mitre locking handle cover 1
103 Torsional spring 1 123 Extension bar 2
104 Insert 1 124 Front table support foot 1
105 Guide rod 2 125 Spring 1
106 Guide rod support 1 126 Mitre location rod spring 1
107 Carrying handle 1 127 Mitre location rod 1
108 Locknut 1 128 Screw 1
109 Washer 2 129 Lock plate for mitre lock rod 1
110 Wave washer 1 130 Mitre angle scale 1
111 Hex bolt 1 131 Base 1
112 Rotary shaft 1 132 Locknut 1
113 Nut 1 133 Fence 1
114 Bevel angle pointer 1 134 Screw 2
115 Hex bolt 1 135 Clamp press plate 1
116 Washer 2 136 Clamp arm 1
117 Table 1 137 Clamp rod 1
118 Mitre pointer 1 138 Locking knob 1
119 Mitre angle locking rod 1 139 Spring ring 1
120 Mitre locking handle 1 140 Press plate 1
