model no. 055-6751-6 | contact us 1-800-689-9928
KEY PARTS DIAGRAM
NOTE:
Before attempting to use your saw, familiarize yourself with all of the operating features and
safety requirements.
1 Switch handle
2 On/Off trigger switch
3 Upper blade guard
4 Lower blade guard
5 Laser
6 Base
7 Table insert
• Set: The distance that the saw blade tooth is bent (or set) outward from the face of the blade.
• Throat plate: A plate inserted in the mitre saw table that allows for blade clearance.
• Through Sawing: Any cutting operation where the blade extends completely through the thickness of
the workpiece.
• Workpiece or Material: The item on which the cutting operation is being done. The surfaces of a
workpiece are commonly referred to as faces, ends and edges.
8 Mitre handle
9 Mitre stop locking lever
10 Positive mitre stop
11 Mounting hole
12 Handhold for transportation
13 Extension wing
14 Fence
WARNING!
Carefully remove the tool and any accessories from the box. Make sure that all items listed in
the packing list are included. Inspect the tool carefully to make sure that no breakage or damage
occurred during shipping.
WARNING!
Do not discard the packing material until you have carefully inspected and satisfactorily operated
the tool.
SAFETY GUIDELINES
4
5
1
2
6
7
8
12
13
11
9
10
14
3
