SETTINGS
6.1.4 Battery type
The factory setting for the battery type is optimal for most installations. In some cases it is still desirable to change this setting.
Adjust the Mass Combi to the applied batteries by adjusting DIP switches SW6 and SW7. Wrong adjustment can cause
damage to your batteries which is not covered by the warranty.
The setting for traction battery should never be used with a battery bank that consists of 2V GEL cells!
If you want… DIP switch A
SW6 SW7
Standard battery (factory setting) OFF OFF
Gel / AGM / spiral battery. During the float stage of the charging cycle the output voltage will be higher (+
0.55V @ 12V / + 1.1V @ 24V)
ON OFF
Traction battery. Charging voltage will be increased during the bulk stage (+ 0.7V) and the absorption
stage (+ 0.4V)
OFF ON
Forced float. When activated, the three stage charging program is changed to a single stage program.
Fixed output voltage: 13.8V (@12V) or 27.6V (@24V)
ON ON
6.1.5 Ground relay
The ground relay function allows you to connect the Neutral conductor (N) of the inverter output circuit to the Safety Ground
(PE / GND) automatically when the Mass Combi is working as an inverter. Refer to local regulations on this issue.
If you want… DIP switch A
SW8
no internal connection between the Neutral (N) and the Safety Ground (PE / GND) when the Mass Combi
is working as an inverter
OFF
the Neutral wire (N) of the inverter output circuit connected to the Safety Ground (PE / GND) when the
Mass Combi is working as an inverter and disconnected when incoming AC-power is applied (charger /
transfer mode).
ON
EN / Mass Combi 12/1200-60 & 24/1200-35 / June 2007 27
