TECHNICAL DATA
9 TECHNICAL DATA
9.1 SPECIFICATIONS INVERTER
Model Mass Combi 12/1200-60 / 230V 24/1200-35 / 230V
Partnumber 36011205 36021205
DC input
Nominal battery voltage 12V 24V
Operating input voltage range 10.0 – 15.0V 19.0 – 31.0V
Absolute maximum voltage range
(No defects)
0.0 – 16.0V 0.0 – 32.0 V
Low battery switch off* (1-30 sec delay) 10.0V ±5% 19.0V ±5%
Low battery switch on* 11.0V ±5% 22.0V ±5%
High battery switch off* (No delay) 15.0V ±5% 31.0V ±5%
High battery switch on* 14.5V ±5% 29.5V ±5%
Max. ripple allowed on DC (No defects) 5 % RMS 5 % RMS
Nominal current at full load 120A 60A
Maximum peak current 240A 120A
Recommended Fuse 160A 80A
Wire size 2x 50mm²/ AWG2/0 2x 35mm²/ AWG0
Recommended batteries 150Ah 150Ah
DC No load power consumption
Off mode 0mA 0mA
High power mode 230V / 0A (120V / 0A)** out < 9W < 9W
Economic mode, 208V/0A (104V/0A)** out < 8W < 8W
Idle mode, 5 pulses per 2½ sec < 0,5W < 0,5W
AC output
Nominal voltage (±5%) 230VAC (190– 240VAC)*
Wave form True sine wave, max 5% distortion, 2½% typical
Frequency 50Hz (60Hz) +/– 0.05% (adjustable by DIP switch)
Maximum continuous output power
(AC-out: 230V, resistive load)
At 25°C / 77°F ambient temperature 1200VA (DC-in 11.0V) 1200VA (DC-in 22.0V)
At 40°C / 104°F ambient temperature 1000VA (DC-in 11.0V) 1000VA (DC-in 22.0V)
>25°C / 77°F derating –0.65% per °C / –1.15% per °F,
Shutdown at 80°C / 176°F internal temperature.
Output power vs. ambient temperature
Surge capability (5 sec, resistive load) 2400W 2400W
Efficiency (100VA up to 1200VA) 90%
Load power factor range All power factor allowed
Over temperature, overload, short circuit, AC on output, high battery, low
battery.
Protections
* adjustable by means of MasterAdjust software
