TECHNICAL DATA
9.3 MISCELLANEOUS
Switch over system
AC transfer fuse Yes, by means of resetable fuse
Reverse polarity protection None.
Overheat protection Yes, derating above 80°C / 176°F on Power Heat sink
Type of Transfer Automatic
Type of Switch 2 pole relay
Continuous rating 25A @ 230V, 35A @ 120V
Transfer speed 25ms max, 10ms typical
Inverter synchronized to line before transfer Yes.
Transfer (interruptible free) Half seamless.
Yes, adjustable via DIP switches, see 6.2.1, or via the remote APC see
3.4.2.
Power sharing mode
Ground relay included for connection of neutral of inverter to ground only
at inverter mode. Standard disabled. See section 6.1.5 to enable.
Ground relay
AC cable size IN & OUTPUT 1,5mm² – 6 mm² (Depending on your electrical installation)
Battery connections Bolt M8 (13 mm diameter).
Slave charger output 5 amps Faston, is switched off in inverter mode
Generator / Shore support Yes
Parallel mode No
Power support mode: Yes
Model Mass Combi 12/1200-60 / 230V 24/1200-35 / 230V
Environmental Specifications
Max dimensions (HxWxD) 371 x 318 x 143 mm 371 x 318 x 143 mm
Weight 7.8kg / 17lbs 7.8kg / 17lbs
Operating temperature range
SPECIFIED, will meet specified tolerances. 0°C to 25 °C / 32 to 77°F 0°C to 25 °C / 32 to 77°F
ALLOWED, may not meet specified tolerances. -25°C to 60°C / -13 to 140°F -25°C to 60°C / -13 to 140°F
NON-OPERATING, storage. -25°C to 85°C / -13 to 185°F -25°C to 85°C / -13 to 185°F
Humidity Max 95% relative humidity, not condensing.
Environment class IP 23
Cooling Mix of conventional and forced air cooling, by DC fans with variable speed.
Fan operation
The fan does operate on a temperature current control related PWM
variable speed control. DC maintenance free fan.
36 EN / Mass Combi 12/1200-60 & 24/1200-35 / EN
