TECHNICAL DATA
EN / Mass Combi 12/1200-60 & 24/1200-35 / June 2007 39
10 ORDERING INFORMATION
Part number Description
6384008000 Industrial DC fuse 80A DIN 00
6384016000 Industrial DC fuse 160A DIN 00
6384516000 Industrial DC fuse 160A DIN 1
6381001000 Fuse base DIN 00 (max. 160A)
6381002000 Fuse base DIN 1 (max. 250A)
79009006 Battery switch 250A with knob
79009005 Battery switch 250A with key
6502001030 Modular communication cable, cross wired, 6 pole, 6 meter / 19 ft
6502100100 Modular communication cable, cross wired, 6 pole, 10 meter / 33 ft
6502100150 Modular communication cable, cross wired, 6 pole, 15 meter / 49 ft
41500500* Battery temperature sensor, incl. 6 meter / 19 ft cable
70405000 Inverter Charger Control (Remote ICC), See section 3.4.1
70405010 AC Power Control Panel (Remote APC) for 230VAC installations, See section 3.4.2
70603250 M-3-R1 Adapter frame for the mounting of a Remote ICC or APC in a Mastervision panel
70403080 Masterlink MICC, remote control panel for Mass Combi. Features: On/Off, status read out, Power Support,
extended battery monitoring functions See section 3.4.3
21730100 PC link RS232-QRS232 (without galvanic isolation) required to use with MasterAdjust software
21730300 PC link RS232-QRS232 ISOLATED (with galvanic isolation) required to use with MasterAdjust software
* standard included with the delivery of the Mass Combi
Mastervolt can offer a wide range of products for your electrical installation, including automatic AC transfer switches, remote
control panels and DC distribution kits
See our website www.mastervolt.com for an extensive overview of all our products
