Mastervolt Mass Combi 12/1200-60

TECHNICAL DATA
Figure 27: Characteristic of the equalize charge cycle (see section 6.2.6) (@ 25°C / 77°F)
FLOAT EQUALIZE FLOAT
Float voltage + 2.25V
= 15.50VDC
Float voltage
= 13.25VDC
10% of Imax
Max equalize time = 6hr
Start equalize cycle by jumper change (disabled when Gel)
= voltage
= current
Figure 28: Temperature compensation characteristic (charge voltage versus temperature)
38 EN / Mass Combi 12/1200-60 & 24/1200-35 / EN
