Load Upper Cleaning Roller & Films
1. Pull the cartridge out while pressing the Cartridge Load/Eject Button to
remove it from the laminator.
-Load Upper Cleaning Roller
2. Align the Cleaning Roller with its hole and push it down until it clicks.
After installation of cleaning roller
Cleaning roller hole
