Matica Lamination Module MC-L2 User Manual
53
Maintenance Instructions
-Supported Cards
The following cards are recommended for the prevention of jams
and the best results.
- International Standard (CR-79, CR-80 ISO 7810)
- CR-80 ( 53.98mm (W) x 85.60mm (L)/ 2.215” x 3.375”)
- CR-79 (51mm (W) x 83.9mm(L)/2.051” x 3.303”)
① Size
- Standard : 0.76mm~1.0mm (30mil~40mil)
② Thickness
- Glossy white
- Free of dirt or grease
- Not contaminated
- Free of scratches or dents
- Completely at
- Static Free
③ Acceptable Cards
- Heavily damaged
- Stained or contaminated
- Scratched
- Bent or deformed
- Embossed
④ Unacceptable Cards
Do not use cards considered unacceptable
as they may damage the parts.
Caution
