Max CPM-100G5 User Manual

4
sides of the body to carry it – neglecting this may damage the plug or cord and cause a fire or electrical shock, as well as this
could cause an injury or trouble.
 When replacing the cutting tool (blade) or mounting/dismounting a tape roll, be sure to turn off the power. Otherwise, you could
be injured by abrupt activation of the machine.
 Note that the cutting edge of the replacement blade is very sharp. Do not touch the tip of the cutting tool (blade) – you may be
injured.
 When not using the machine for a long time, such as consecutive holidays, be sure to disconnect the power plug from the
electrical outlet, for safety.
 Data saved in a personal computer cannot be saved permanently. We cannot be responsible for damage due to loss of data
attributable to trouble or repair, or lost profit.
 Do not directly touch the connector with hand. Static electricity may cause trouble.
Disclaimers
MAX will not be held responsible for any damages that occur as a result of not following the
instructions in this manual, damages and lost profits resulting from not being able to use the
machine (malfunction), or any relevant secondary damages.
PRODUCT SPECIFICATIONS
Product
CPM-100G5
CPM-100HG5
Printer section
Printing method
Thermal transfer
Printing density
203dpi
400dpi
Printing speed
25 mm/sec. (1”/sec.)
Cutter section
Resolution
0.025 mm/step (0.001”/step)
Cutting speed
120 mm/sec. (4.7”/sec.) at maximum
Maximum output range
100 mm (3.9”) x 2000 mm (78.7”)
Interface
USB2.0 full speed
USB2.0 full speed
LAN 10baseT/100baseTX
Working environment
Temperature: 10-35C (50-95°F),
Humidity: 35-80 % (No dew condensation allowed)
Power source
AC 100 - 240 V 50/60 Hz 1A
Power consumption
85 W
Outer dimensions
330 mm (13.0”) x 320 mm (12.6”) x 320 mm (12.6”)
(W) x (D) x (H)
Mass (Main body only)
9 kg (19.8lbs.)
*Design, specifications, and the like are subject to change without notice.
