1. Confirming the Package Contents
Open the package and confirm that all of the following items are included.
<1> CPM-100G5/CPM-100HG5
<2> AC cable
<3> Blade (1 pc.)
<4> Tweezers
<5> Squeegee
<6> Tool Holder
(Attached upon
shipment)
<7> Tool holder
replacing spanner
<8> Application
Software CD
<9> Installation Manual
(this manual)
2. Component Units and Their Functions
[Front of Main Body] [Back of Main Body]
[Main Key Functions]
Power key : Used to turn on/off the power.
Tape roll feed keys : Used to feed the tape roll.
LED lamp : Illuminated in green when the Power switch is turned on. It is illuminated or blinks in red
when informing you of an error.
Door Cover
Vinyl Outlet
LED Lamp
Cutting Pressure Control Dial
Power Key
Vinyl Feed Key (Forward)
Vinyl Feed Key (Back)
Scissors Key
Handle (Right and Left)
Opening/Closing Lever
Thermal Head
Cutting Tool
Cutting Head
Vinyl Retainer
Sprocket
Dust Removal Lever
(Silver)
Power Connector
Vinyl Holder
USB Connector
LAN Connector
(Only CPM-100HG5)
