MAXDATA PLATINUM - Memory

20
Server Board Installations and Upgrades
Memory
Only DDR266 compliant SDRAM is supported by the server board. Install from 256 MB to
12 GB of registered, ECC memory, using up to six DIMMs. A 1U chassis requires low-profile
(LP) 1.2-inch DIMMs.

NOTE
Only DDR 266 is supported with a 533 MHz Front Side Bus.
DIMMs must be installed in pairs and in the following order: 1B and 1A, 2B and 2A, 3B
and 3A.
Installed DIMMs must be the same speed and must all be registered.
Figure 4. Installing Memory






