MAXDATA PLATINUM Server Board
1
1
DescriptionDescription
Server Board Features
Table 1. Server Board Features
Feature
Description
Processors
Dual processor slots supporting Intel
®
Xeon™ processors in an INT3/FCPGA Socket
604 package
Chipset
Intel
®
chipset E7501:
Supports 533 MHz Front Side Bus (FSB)
MCH memory controller (Northbridge)
ICH3 I/O controller (Southbridge)
P64H2 64-bit I/O hub
Memory
Six dual inline memory module (DIMM) slots support:
• DDR 266 compliant, ECC, registered, 72-bit, 168-pin, DIMMs
• From 256 MB to 12 GB of memory
Graphics
Integrated onboard ATI RAGE XL PCI SVGA controller
Video Memory
8 MB SDRAM of video memory
PCI bus
Two PCI riser slots capable of supporting either of the following configurations:
• 1U configuration: one full-length, full-height 64-bit PCI riser slot and one Low Profile
(LP) 64-bit PCI riser slot
• 2U configuration: three full-length, full-height 64-bit PCI riser slots and three LP 64-bit
PCI riser slots
Network
Dual on-board 10/100/1000 Network Interface Controller (NIC)
System I/O
One PS/2 keyboard/mouse port (6 pin DIN connectors)
One VGA video port (15 pin connector)
Two external USB ports, internal connector providing two additional USB
One external serial port (RJ-45), one internal COM 1 header
One external SCSI port (SCSI server board only), one internal
Two NIC ports (RJ-45)
Form Factor
Server ATX form factor
