Operating
Correcting the distortion (continued)
1.
Select SETUP with the ▲/▼ buttons and press the ► or ENTER button.
2.
Select one of the corners or sides to be adjusted with the ▲/▼/◄/►
buttons and press the ENTER or button.
3.
Adjust the selected part as below.
● For adjusting a corner, use the ▲/▼/◄/► buttons to adjust the position of
the corner.
● For adjusting the upper or lower side, use the ▲/▼ buttons to adjust the
distortion of the side.
● For adjusting the left or right side, use the ◄/► buttons to adjust the
distortion of the side.
● To adjust another corner or side, press the ENTER or
button and follow
the procedure from step 2.
4.
This projector is equipped with a memory feature for PERFECT FIT
adjustment. Up to 3 sets of adjustments can be stored.
● SAVE:
To store the current PERFECT FIT adjustment, select one of the "SAVE"
options numbered 1 to 3 (number of the memory) with the ▲/▼ buttons and
press the ►, ENTER or
button.
The current data being stored are lost by saving new data.
● LOAD:
To recall stored adjustments, select one of the "LOAD" options numbered
1 to 3 (number of the memory) with the ▲/▼ buttons and press the ►,
ENTER or
button.
The current adjusted condition is lost by loading data. If you want to keep
the current adjustment, save it before performing a LOAD function.
• The LOAD functions whose linked memories have no data are
skipped.
• There may be some noise and the screen may icker for a moment when
loading data. This is not malfunction.
NOTE
