IMAGE menu
Item Description
V POSITION
Using the ◄/► buttons adjusts the vertical position.
Down
ó
Up
• Over-adjusting the vertical position may cause noise to appear on
the screen. If this occurs, please reset the vertical position to the
default setting. Pressing the RESET button when the V POSITION
is selected will reset the V POSITION to the default setting.
• When this function is performed on a video signal, the range of
this adjustment depends on OVER SCAN (

55) setting. It is not
possible to adjust when OVER SCAN is set to 10.
•
This function is unavailable for a signal from the LAN, USB TYPE A,
HDMI 1 or HDMI 2 port.
H POSITION
Using the ◄/► buttons adjusts the horizontal position.
Right
ó
Left
•
Over-adjusting the horizontal position may cause noise to appear on
the screen. If this occurs, please reset the horizontal position to the
default setting. Pressing the RESET button when the H POSITION is
selected will reset the H POSITION to the default setting.
• When this function is performed on a video signal, the range of
this adjustment depends on OVER SCAN (

55) setting. It is not
possible to adjust when OVER SCAN is set to 10.
•
This function is unavailable for a signal from the LAN, USB TYPE A,
HDMI 1 or HDMI 2 port.
H PHASE
Using the ◄/► buttons adjusts the horizontal phase to eliminate
icker.
Right
ó
Left
• This item can be selected only for a computer signal or a component
video signal. This function is unavailable for a signal from the LAN,
USB TYPE A, HDMI 1 or HDMI 2 port.
(continued on next page)
