Maxray DX3000 - Product Component Explanation

USER Manual
20
Battery pack cover
Label
Hand strap
Low battery indicating light
X-ray field
X-ray exposure
button
Power button
2.35” Graphic LCD
Remote control
connector
X-ray exposure
indicating light
Time setting button
Product logo
6.3 Product Explanation
6.3.1 Main body parts
The parts of the main body are labeled as follows:
Figure 6.2 Main body parts
