Output terminal (+)
Output terminal (-)
Battery pack label
Charging terminals
Charge indication light
Battery pack holder
DC input connector
6.3.4 Battery pack and charging device parts
1
○ Battery pack parts
Figure 6.8 Battery pack parts
 Battery pack label: Indicates the battery model name, manufacturer's address
and serial numbers, as well as providing certain precautions.
 Output terminal (+,-): Provides power when the battery pack is inserted into the
device.
2
○ Charging cradle parts
Figure 6.9 Charging cradle parts
