Charge source Jack
Charging adaptor
label
Output indicating light
AC Input
connector
AC power cord
(Top)
(Bottom)
Charge indication light: Indicates the status of battery charge using three
different colors (red - charging; green - fully charged; yellow - charging error)
Charging terminals: Connect the output terminals of the battery pack to the
charging terminals of the charging cradle to charge the battery.
Battery pack holder: Holds the battery pack in place while its being charged.
DC input connector: Receives charging power from charging adaptor
2
○ Charging adaptor parts
6.10 Charging adaptor parts
Charge source jack: Provides DC output power from the adapter
