The Rinse Sequence
n No temperature can be programmed because a Rinse is only possible with cold water.
Menu Item Description Default Limits
Inlet 3 Inlets can be programmed.
The suggested Inlet Valves are related to the
temperature and the Soap Box to be used.
IMPORTANT: If you insert Inlet Valves other than those
suggested, problems can occur at the water fill process.
11, 12, 17 1, 2, 3, 4, 7
Level The suggested water level depends on the Machine Type. Normal
High
See Table A-3
RPM The suggested RPM depends on the Machine Type. – See Table A-5
Detergents Menu…
Supply 1, …, 8
Time selection for external liquid soap supplies.
You can program up to 4 supplies at the same time. If you have
programmed more than 4 supplies an error message will be
generated.
Reset the time of the supplies back to 0. Only 4 non-zero times
values can be programmed.
– Liquid soap supplies must be switched on in the
Configuration Menu.
0 sec 0–99 sec
On Time The wash action, motor On Time.
Gentle wash action: 3 sec.
(The suggested default values can be adjusted in the
Initialization Menu)
12 sec 1–99 sec
Off Time The wash action, motor Off Time.
Gentle wash action: 12 sec.
(The suggested default values can be adjusted in the
Initialization Menu)
3 sec 0–99 sec
Time The Rinse Sequence Time.
(for 0 minutes the Rinse sequence will be skipped)
(programmable in steps of 0.5 minutes)
2 min 0–99.5 min
Signal When a signal is programmed, a pause will be introduced at the
end of the Wash Step. This allows the operator to add soap for
the next step. A buzzer signal warns the operator that the cycle
has been interrupted.
No No/Yes
Prewash Wash Cool Down Rinse Final Rinse Soak Spray No Wash
