The Cool Down Sequence
n After a hot wash you can program a Cool Down Sequence to avoid temperature shock and shrinking of the garments.
n The drain step after the hot wash must be put on NO DRAIN.
n No inlets are programmable:
– Washer with 2 water inlets: inlet 1 is the standard inlet.
n The water level cannot be programmed as the process of adding and draining water does not allow this.
Menu Item Description Default Limits
Temperature The water temperature 140°F
(60°C)
33.8–140°F
(1–60°C)
RPM The suggested RPM depends on the Machine Type. –
Drain Valve Only available on washers with both a normal Open and
normal Closed Drain valve.
1 1–2
On Time The wash action, motor On Time.
Gentle wash action: 3 sec.
(The suggested default values can be adjusted in the
Initialization Menu)
12 sec 1–99 sec
Off Time The wash action, motor Off Time.
Gentle wash action: 12 sec.
(The suggested default values can be adjusted in the
Initialization Menu)
3 sec 1–99 sec
Time The programmed time = time needed to decrease the
water temperature.
Once the programmed temperature has been reached,
the next Sequence will be started.
(for 0 minutes the Cool Down sequence will be skipped)
(programmable in steps of 0.5 minutes)
IMPORTANT: If a short time is programmed, the water
temperature will decrease fast.
Recommendation: Program 1 minute for each 37.4°F (3°C)
temperature drop.
Example: For a hot wash of 194°F (90°C) and a Cool Down
Sequence of 140°F (60°C) a time of about 86°F (30°C)/
37.4°F (3°C) = 10 minutes should be programmed for the Cool
Down Sequence.
7 min 0–99.5 sec
Signal When a signal is programmed, a pause will be introduced at
the end of the Wash Step. This allows the operator to add
soap for the next step. A buzzer signal warns the operator
that the cycle has been interrupted.
No No/Yes
IMPORTANT: Do not program a drain sequence before a cool down sequence.
Prewash Wash Cool Down Rinse Final Rinse Soak Spray No Wash
