The Wash Sequence
Menu Item Description Default Limits
Temperature The water temperature. 140°F
(60°C)
33.8–197.6°F
(1–92°C)
Inlet The suggested Inlet Valves are related to the temperature
and the Soap Box to be used.
NOTE: If you insert other Inlet Valves than the suggested
ones, problems can occur at the water fill process.
12-13-16-18 11–18
Level The suggested water level depends on the Machine Type. Normal Low See Table A-3
RPM The suggested RPM depends on the Machine Type. – See Table A-5
Detergents Menu. . .
Supply 1, ..., 8
Time selection for external liquid soap supplies. You can program
up to 4 supplies at the same time, attempting to program more than
4 supplies will generate an error message.
Reset the time of the supplies back to 0. Only 4 non-zero times
values can be programmed.
– Liquid soap supplies must be switched on in the
Configuration Menu.
0 sec 0–9 sec
On Time The wash action, motor On Time.
Gentle wash action: 3 seconds
(The suggested default values can be adjusted in the
Initialization Menu)
12 sec 1–99 sec
Off Time The wash action, motor Off Time.
Gentle wash action: 12 seconds
(The suggested default values can be adjusted in the
Initialization Menu)
3 sec 1–99 sec
Time The Wash Sequence Time.
(for 0 minutes the Wash Sequence will be skipped)
(programmable in steps of 0.5 minutes)
7 min 0–99.5 min
Signal When a signal is programmed, a pause will be introduced
at the end of the Wash Step. This allows the operator to add soap
for the next step. A buzzer signal warns the operator that the cycle
has been interrupted.
No No/Yes
Prewash Wash Cool Down Rinse Final Rinse Soak Spray No Wash
