Maytronics M550 - 5 Using the Robotic Pool Cleaner; Setup

5
CLASSIC 15+ Robotic Pool Cleaner | User Instructions
5.1.25.1.1
5.1.3 5.1.4
5.1.5
1
2
11cm/4 in
minimum
11cm/4 in
minimum
3.5m/12 ft.
5.1 Setup
5. USING THE ROBOTIC POOL CLEANER
Position the power supply
at approximately the middle of the
long side of the pool. To prevent
electrocution, position the power
supply at least 11 cm / 4 in above
ground and 3.5 m / 12 ft away
from the edge of the pool.
Unwind the blue cable and stretch it out completely so that
it has no kinks.
Attach the blue cable to the
power supply: Insert the cable with the
jut on the connector (1), lined up with
the groove in the socket on the power
supply, and turn clockwise (2).
Place the robotic pool cleaner in
the pool. Release it and let it sink to the
floor of the pool.
Make sure that the blue cable is free of
any obstacles.
Connect the power supply to a
100 - 240 volt AC outlet.
Before using the robotic pool cleaner for the first time, perform the following steps:
