Instrument Cluster
① Tachometer
② Multi-information Display
③ Engine Coolant Temperature Gauge
④ Fuel Gauge
⑤ Dashboard Illumination Switch
⑥ Speedometer
⑦ TRIP Switch
Speedometer
The speedometer indicates the speed
of the vehicle.
Driving
Instrument Cluster
5-24
Mazda3_8LX5-EA23E_Edition2_new 2023-4-17 20:22:43
