Mazda 3 2004 - Spare Tire and Tool Storage

Jack
To remove the jack
4-Door
1. Remove the trunk board.
2. Remove the cover.
3. Turn the wing bolt and jack screw
counterclockwise.
1. Wing bolt
2. jack screw
5-Door
1. Remove the luggage board.
2. Remove the jack.
To secure the jack
4-Door
1. Insert the wing bolt into the jack
with the jack screw pointing to the
front and turn the wing bolt
clockwise to temporarily tighten it.
2. Turn the jack screw clockwise.
Other Equipment
Spare Tire and Tool Storage
7-53
