How to Use the Wireless
Charger (Qi)
1. Start the engine.
The power for the Wireless Charger
(Qi) turns on and the LED indicator
turns on.
2. Place a device compliant with the
Qi Wireless Charging standard
(portable device with a maximum
power consumption of 5 W or 15
W or below) in the center of the
charging area on the tray.
1. Charging area
2. LED indicator
The LED indicator turns on in amber
or green when charging starts.
Charging starts when all the doors
and liftgate are closed.
For details on the LED indicator, refer
to the following LED indicator table.
Charging status display
The charging status of the Wireless
Charger (Qi) can be checked with the
LED indicator or the icon displayed on
the center display.
Illumina-
tion/flash
pattern
Icon indi-
cation
Status
Does not
turn on
―
Indicates that charg-
ing is turned off.
Illumina-
tion/flash
pattern
Icon indi-
cation
Status
Turns on in
white
Indicates that charg-
ing is possible.
Turns on in
amber
Indicates normal
charging.
Turns on in
green
Indicates fast charg-
ing
*1
.
Flashes in
white
Indicates that the
charging conditions
are not met.
Flashes in red
Indicates that charg-
ing is not possible
because a high tem-
perature is detected.
Indicates that charg-
ing is not possible
because foreign mat-
ter is detected.
Turns on in
red
Indicates that there
is a problem with
Wireless Charger
(Qi) and it needs to
be repaired. Consult
an Authorized Maz-
da Dealer.
*
1 Some mobile devices can switch
between normal charging and fast
charging.
NOTE

Charging
efficiency
may be reduced
or charging may not be possible
depending on the use environment
and conditions.
Other Equipment
Wireless Charger (Qi)
