2. Remove the fuse block cover.
3. If any fuse but the MAIN fuse is
blown, replace it with a new one of
the same amperage rating.
1. Normal
2. Blown
WARNING
Do not replace the main fuse by
yourself. Have an Authorized
Mazda Dealer perform the
replacement.
Replacing the fuse by yourself is
dangerous because the MAIN fuse
is a high current fuse. Incorrect
replacement could cause an
electrical shock or a short circuit
resulting in a fire.
Do not replace the main fuse and
multiplex slow blow fuse by
yourself. Have an Authorized
Mazda Dealer perform the
replacement.
Replacing these fuses by yourself is
dangerous because they are high
current fuses. Incorrect replacement
could cause an electrical shock or a
short circuit resulting in a fire.
4. Reinstall the cover and make sure
that it is securely installed.
Inspection and Servicing/Cleaning
Engine Compartment Inspection
9-25
