b) Switch the vehicle power ON.
c) Press up the wiper switch to the
MIST position 2 times.
Replacing Rear Windshield Wiper
Blade rubber
CAUTION
To prevent damage to the wiper arm
and other components, do not move
the wiper by hand.
1. Remove the cover.
2. Remove the stopper.
3. Raise the wiper arm and rotate the
wiper blade to the right until it
unlocks, then remove the blade.
CAUTION
To prevent damage to the rear
window, do not let the wiper arm
fall on it.
4.
5. Remove the metal stiffeners from
the blade rubber and install them in
the new blade rubber.
Inspection and Servicing/Cleaning
Vehicle Exterior Inspection
9-35
